40 MHz sine
50 MHz square
Single channel
100 MSa/s sample rate
12-bit vertical resolution
Multiple "standard" waveforms including sine, square, triangle, ramp, pulse and sin(x)/x
1M point maximum waveform length
External ARB clock input
Waveform storage by Compact Flash memory cards
Complex waveform sequencing and looping
Pulse train pattern generation for up to 10 pulses
Built-in trigger generator, gated & triggered burst modes
Interfaceable via RS-232, GPIB (IEEE-488.2) and USB
"Waveform Manager Plus" for Windows software included
