Model	N.Decades	Sections microF	Total Capacity microF
CC-B/5DC1	5	10 x ( 0,0001+0,001+0,01+0,1+1)microF	11,111
CC-B/4DC1	4	10 x ( 0,0001+0,001+0,01+0, 1)microF	1,111
CC-B/4DC2	4	10 x ( 0,001+0,01+0,01+0,1+1)microF	11,11
CC-B/3DC1	3	10 x ( 0,0001+0,001+0,01) microF	0,111
CC-B/3DC2	3	10 x ( 0,001+0,01+0,1) microF	1,11
CC-B/3DC3	3	10 x ( 0,01+0,1+1) microF	11,1

Plastic not polarized film condensers;

terminals according to safety rules;

plastic box, panel of aluminium with serigraphy;

double insulation.

Precision: 1 %.

Working voltage: 400Vdc or 250 Vac.

Drift in temperature: 80 ppm / °C

Model	N.decades	Range	Precision at 20 °C	Dimensions (mm)
C50	5	Da 10x100 pF a 10x1 µF	1%	420 x 80 x 60
C1	1	10 x 1 nF	1%	82 x 82 x 60
C2	1	10 x 10 nF	1%	82 x 82 x 60
C3	1	10 x 100 nF	1%	82 x 82 x 60
C4	1	10 x 1 µF	1%	82 x 82 x 60
