The EN-106 home modulator sends audio / video signal from TV satellite receivers, closed-circuit television cameras (CCTV) or video players to a TV which uses DVB-T (Digital Terrestrial Television) standard.

Programming the EN-106 modulator is very easy through its keyboard and display. It also provides connection to the PC via USB.

The EN-106 includes an RF combiner on which a channel modulated from existing antenna signals can be added easily. It is a passive combiner that works even if the modulator is off. It can also be used in series with other EN-106 modulators and with any other RF signal so the number of channels in the coaxial cable on the SMATV system can be increased as desired.

INPUTS Video Audio	1 x PAL?/?NTSC / SECAM 2 x Mono /?Stereo
COMPRESSION Video Audio Insertion of DVB Tables LCN Programming	MPEG-2 MP@ML. 720x576, 25 fps (PAL), 720x480, 30 fps (NTSC). MPEG-1 Layer II Stereo, Mono, Dual, Joint Stereo SDT, NIT, EIT Yes
FREQUENCY MARGIN	From 100 to 865 MHz (channels S01 to C69)
CONNECTIONS Video Audio RF Power supply	RCA female 75 O RCA female 2 x F female (loopthrough) 75 O External Power supply 220V / 12 V
