MEGGER MIT480/2 MIT481/2 MIT485/2 Insulation Tester for Communications 500V

Code: MIT480/2 MIT481/2 MIT485/2 1004-741 1004-742




Datasheet PDF, 0.31 Mb

Description

MEGGER MIT480/2 series

The range consists of two instruments:

MIT481/2: 50 V, 100 V, 250 V, 500 V* + storage
MIT485/2: 50 V, 100 V, 250 V, 500 V* + storage + download + recharge ready
* Gated access – prevents accidental selection


Insulation and continuity testers for communications engineers
The MIT480/2 series offers handheld insulation and continuity testers with up to 500 V and 100 GΩ range. Features include gated voltage access, rechargeable options, differential measurement, 600 V AC/DC voltage measurement, and Bluetooth® data transfer. Available in MIT481/2 and MIT485/2 models, the latter includes download and recharge capabilities. The testers are IP54-rated for weather resistance.

About the product
  • Insulation testing up to 500 V and 100 GΩ range in a hand held instrument
  • 3-wire connection for A, B, and E (Tip, Ring and Ground/Earth) connection
  • Gated access to 500 V to prevent accidental damage
  • Rechargeable options for mains and car charging
  • Single range, faster continuity testing from 0.01 Ω to 1 MΩ
  • Differential measurement capability
  • Stabilised insulation test voltage
  • 600 V Trms AC and DC voltage measurement
  • Test result storage and Bluetooth® downloading
  • CAT IV 600 V and IP 54



The MIT480/2 series of insulation and continuity testers replace the original MIT480 range and are designed specifically for the telecommunications and cable testing markets. The new units feature a redesigned case, back stand, and six-cell battery compartment with separate fuse access. All instruments are over-molded for increased protection and have an IP54 weatherproof rating.

The MIT480/2 series uses a three-terminal measurement design that permits the connection of all three test leads for A, B, and E (or Tip, Ring and Ground/Earth). The measurement pair can be selected from the A-B-E (T-R-G) button on the front panel and the selection is confirmed in the display. You don't need to disconnect the test leads to measure individual pairs.

Alternatively, the units can be used as a conventional two-terminal instrument.






Standard accessories

Description Order Code
Language group 1 - English - French - German - Dutch
MIT481/2 - 3 terminal 50 V to 500 V +
storage and recall 1004-741
MIT485/2 - as MIT481/2 + Bluetooth® download 1004-742
Language group 2 - English - Spanish - Italian - Portuguese
MIT481/2 - 3 terminal 50 V to 500 V +
storage and recall 1006-752
MIT485/2 - as MIT481/2 + Bluetooth® download 1006-758
Language group 3 - English - Arabic - Turkish - French
MIT481/2 - 3 terminal 50 V to 500 V +
storage and recall 1006-753
MIT485/2 - as MIT481/2 + Bluetooth® download 1006-759
Language group 4 - English - Czech - Slovak - Polish
MIT481/2 - 3 terminal 50 V to 500 V +
storage and recall 1006-754
MIT485/2 - as MIT481/2 + Bluetooth® download 1006-760
Language group 5 - English - Chinese - Japanese - Korean
MIT481/2 - 3 terminal 50 V to 500 V +
storage and recall 1006-755
MIT485/2 - as MIT481/2 + Bluetooth® download 1006-761
Language group 6 - English - Hungarian - Romanian -
Russian
MIT481/2 - 3 terminal 50 V to 500 V +
storage and recall 1006-756
MIT485/2 - as MIT481/2 + Bluetooth® download 1006-762
Language group 7 - English - Finnish - Norwegian - Swedish
MIT481/2 - 3 terminal 50 V to 500 V +
storage and recall 1006-757
MIT485/2 - as MIT481/2 + Bluetooth® download 1006-763
Description Order Code

Included accessories
Red/Black silicone test leads with prods and clips
SP5 Switched probe (not MIT400/2)
Owners Information CD
Batteries 6 x AA Alkaline
Hard carry case


Recommended options

Optional accessories
Mains Charger kit (MIT485/2 only) 1007-464
12 V DC battery charger (requires mains charger kit) 1004-183
Switched probe SP5 1007-157
Test lead set and crocodile clips 1002-001
2 wire 500 mA fused test lead set 1002-015
Batteries (6 x NiMH) 1002-735
