PXI Switch SPDT Module 26-channels 2A Agilent M9130A

• 34-channel portable logic analyzer
• 48-channel pattern generator
• 4 GHz (250 ps) timing zoom with 64 K memory
• 1.0 GHz / 500 MHz (half / full-channel) conventional timing with deep memory
• up to 250 MHz State clock rates
• up to 250 Mb/s Data rates
• up to 32 M acquisition memory depth



• 6.5 digit
• PCI PXI Modular Digital Multimeter
• 40 ppm accuracy
• Measurement speeds up to 20,000 rdgs/s
• DCV, DCI, ACV, ACI, 2- and 4-wire resistance



• 3 Hz to 3.6, 8.4, 13.6, or 26.5 GHz
• 10 MHz (standard), 25, 40, or 140 MHz analysis bandwidth
• Basic EMI precompliance measurement capability available
• Advanced analysis of more than 70 signal formats



• 9 kHz to 3.0 or 7.5 GHz Frequency range
• 10 MHz (standard), 25 MHz (optional) analysis bandwidth
• Basic EMI precompliance measurement capability available
• Standards-based PowerSuite: channel power, OBW, ACP, CCDF, SEM



• 1 mHz to 50 MHz
• 1 Channel
• 5 ns to 200 ms variable transition time
• Up to 10 Vpp into 50 O (20 Vpp into open circuit)



• Frequency options:
• 9 kHz - 4.5 GHz/ 6.5 GHz/ 8.5 GHz
• 100 kHz - 4.5 GHz/ 6.5 GHz/ 8.5 GHz (with bias tees)
• 300 kHz - 14 GHz/ 20 GHz (with bias tees)



• Quad 4-channel multiplexers
• DC to 3 GHz, 50 Ohm
• High isolation, low VSWR
• 30V, 0.5A, 10W switching
• SMA connectors



• 200 MHz bandwidth
• 2 analog channels
• 1GSa/s per channel sample rate



• Two SPDT terminated switches
• 4 GHz, 20 GHz, or 26.6 GHz options
• High isolation, low VSWR
• Up to 50W switching



• Hi-Speed USB 2.0 (480 Mbps)
• 32 Input opto-isolated lines
• 32 Output opto-isolated lines
• Functions as standalone or modular unit
• Up to 1250 Vrms isolation protection
