Handheld Digital Data Logging Multimeter 5 digit Agilent U1252A U1252B

Code: Agilent U1252A U1252B




Datasheet PDF, 0.36 Mb

Description

  • 5 digit
  • 50,000 count dual display
  • 0.025% basic DCV Accuracy
  • LED with backlight
  • True RMS Measurement (AC+DC)
  • J & K-Type temperature measurements
  • Internal logging memory: 200 points
  • 20 MHz Frequency counter
  • Programmable square wave generator
  • Built-in battery charger capability
  • Optional USB connectivity to PC(U1173A cable is required for connection to PC’s USB port, software comes bundled with DMM)
  • Cat III 1000V (IEC61010 compliant) safety rating
  • Multi-function tilt stand
  • Three-year warranty


Standard accessories

Included with U1252A model:
  • Alligator clips
  • SMT grabbers
  • Fine-tip test probes
  • Test probe leads (4-mm)
  • Test probe leads (19-mm)
  • Mini grabber
  • Rechargeable Ni-MH battery with power adapter
  • Soft carrying case
  • Certi?cate of Calibration
  • Test Report
  • Quick Start Guide

Included with U1252B model:
  • Alligator clips
  • Test probe leads (4-mm)
  • Test probe leads (19-mm)
  • Rechargeable Ni-MH battery with power adapter
  • Certi?cate of Calibration
  • Test Report
  • Quick Start Guide
