PXI RF Matrix Switch 3GHz 1 x 16, 50 Ohm Agilent M9149A

Code: Agilent M9149A




Datasheet PDF, 3.68 Mb

Description

  • RF switching to 3 GHz for routing signals to your measurement equipment
  • 1x16 50 ohm RF switch multiplexer to 3GHz
  • 30V, 1A, 10W switching
  • 40 dB isolation at 1 GHz
  • 1.3 dB insertion loss at 3 GHz
  • High-quality SMB connectors
  • Low insertion loss and VSWR for better signal integrity
