Agilent 81180A Arbitrary Waveform Generator 4.2 GSa/s

Code: Agilent 81180A




Datasheet PDF, 5.93 Mb

Description

  • 10-MS/s to 4.2-GSa/s sample clock control
  • 2 GHz IQ modulation bandwidth
  • 12 bit vertical resolution
  • 1 or 2 channel, coupled or uncoupled
  • Two 2-channel systems can be synchronized to form a 4-channel system
  • Interchannel skew control from -3 ns to +3 ns with 10-ps resolution
  • Three software-selectable amplifers optimized for:
- I/Q applications with 1 GHz, differential DC-coupled output
- Maximum bandwidth and fatness for direct RF applications with AC output bandwidth to > 1.5 GHz
- Time domain applications with low overshoot and jitter
  • 16 M points or 64 M points per channel
  • 8-bit external input for dynamic control of segments and sequences
  • Advancedsequencing    scenarios defne  stepping, looping and conditional jumps of waveforms or waveform
  • sequences for best memory usage
  • Smart trigger allows trigger hold-off and programmable pulse width
  • Trigger input is programmed to wait for waveform end or abort waveform and restart
  • Two markers for each channel have controlled marker positions, widths and levels
  • Markers do not reduce DAC bits
  • Internal fash memory     stores settings and waveforms
  • Remote control through LAN, USB and GPIB
  • Waveforms and instrument settings can be uploaded from disk-on-key
  • Integration in:

- MATLAB®

- NI LabVIEW

- Agilent  Signal Studio1

- Agilent  BenchLink Waveform Builder Pro2
