Automatic Vision Inspection Machine AVIM

• Measure the pitch diameter of lead screw and external thread
• Ball tip diameter can be customized according to workpieces. Diameter of trapezoidal screw or external thread ball tips: ØD=0.5×pitch P/cos (thread angle α/2)
• Ball tips diameter ØD of ball screw is corresponding steel ball specification



• Linear ball bearings for ten million times use
• Ø28mm stem suitable for reinforced clamping
• Absolute encoder, the original data remains after power off



• The frame is made of aluminum magnesium alloy with light weight and high strength
• Optional accessory: 0.01mm or 0.001mm digital/dial indicators



• Stainless steel base
• Supplied with pointed tip and ball tip



• Automatic measurement
• Semi-automatic measurement is possible, operate by hand and find graduation lines by eyes, for indicators with stains on dial faces
• Automatic zero setting



• Measure outside or inside chamfer height
• Suitable for diameter of bores≥6mm, chamfer angle ≥30° α
• Setting gauge is included



• IP54 dust/waterproof (when cap is lifted, no dust/waterproof)
• Absolute encoder, the original data remains after power off
• Automatic power off



• Full plastic housing with tempered glass panel, extremely hard, wear-resistant and scratch-resistant
• Full-digital multi-color high resolution (640×480 pixels) TFT LCD display
• The operation interface style can be selected according to the working environment, and the brightness of LCD can be set freely



• Non waterproof
• Measure the radius of arc less than half round
• Buttons: on/off, zero, mm/inch



• Carbide tipped scriber
• Made of stainless steel (except the base)
• Satin chrome plated scale
