Thread/Lead Screw Pitch Diameter Snap Gauge 2165-20

Code: 2165-20




Datasheet PDF, 0.76 Mb

Description

Thread/Lead Screw Pitch Diameter Snap Gauge
Code: 2165-20

  • Measure the pitch diameter of lead screw and external thread
  • Ball tip diameter can be customized according to workpieces. Diameter of trapezoidal screw or external thread ball tips: ØD=0.5×pitch P/cos (thread angle α/2)
  • Ball tips diameter ØD of ball screw is corresponding steel ball specification
  • Probe retracting range: 3mm, measuring force: 20N

Code:  2165-20
Range:  3-20mm
Accuracy:  ±5µm
