Handheld Loop Calibrator Fluke 705

Code: Fluke 705




Datasheet PDF, 0.53 Mb

Description

  • 0 to 28 V DC Voltage measure
  • 0 to 24 mA Current measure
  • 0 to 20 mA Current source / simulate
  • A large display and simple, pushbutton interface for ease of use
  • Simultaneous mA and % readout for quick, easy interpretation of readings
  • mA accuracy of 0.02%
  • Push button 25% steps for fast, easy linearity checks
  • "Span Check" for fast confirmation of zero and span
  • Selectable slow ramp, fast ramp, and step to provide smooth outputs for valve slewing and loop functional tests
  • 24 volt internal loop supply, so you can power and read a transmitter at the same time without carrying a DMM
  • Single 9V battery that is easily changed
  • 0 - 20 mA or 4 - 20 mA default start up modes
  • Safety conformance CSA C22.2 No. 1010.1:1992


Standard accessories

  • AC70A Alligator Clips
  • C10 protective yellow holster with Flex-Stand™
  • Instruction sheet
  • TL75 safety-designed test lead set
  • NIST- traceable calibration report and data
