High Voltage Oscilloscope Probe with Readout 100x attenuation Testec TT-HV

Code: Testec TT-HV




Description

TT-HV 150RA  Readout 100:1, 300MHz

Attenuation Ratio: x100

Input Impedance: 100Ω, 4 pF

Bandwidth: 300 MHz

Rise Time: 1,2 ns

Cable Length: 1,2 m

Compensation Range: 10..50 pF

Max. Input Voltage: 1500Vp CAT I, DC incl. Peak AC (derating with frequency)





TT-HV 151RA  Readout 100:1, 200MHz

Attenuation Ratio: x100

Input Impedance: 100Ω, 6 pF

Bandwidth: 200 MHz

Rise Time: 1,8 ns

Cable Length: 2,0 m

Compensation Range: 10..50 pF

Attenuation Ratio: x100

Input Impedance: 100Ω, 4 pF

Bandwidth: 300 MHz

Rise Time: 1,2 ns

Cable Length: 1,2 m

Compensation Range: 10..50 pF

Max. Input Voltage: 1500Vp CAT I, DC incl. Peak AC (derating with frequency)



TT-HV 250RA  Readout 100:1, 300MHz

Attenuation Ratio: x100

Input Impedance: 100Ω, 4 pF

Bandwidth: 300 MHz

Rise Time: 1,2 ns

Cable Length: 1,2 m

Compensation Range: 10..50 pF

Attenuation Ratio: x100

Input Impedance: 100Ω, 4 pF

Bandwidth: 300 MHz

Rise Time: 1,2 ns

Cable Length: 1,2 m

Compensation Range: 10..50 pF

Max. Input Voltage: 2500Vp CAT I, DC incl. Peak AC (derating with frequency)





TT-HV 250RA  Readout 100:1, 300MHz

Attenuation Ratio: x100

Input Impedance: 100Ω, 6 pF

Bandwidth: 200 MHz

Rise Time: 1,8 ns

Cable Length: 2 m

Compensation Range: 10..50 pF

Attenuation Ratio: x100

Input Impedance: 100Ω, 4 pF

Bandwidth: 300 MHz

Rise Time: 1,2 ns

Cable Length: 1,2 m

Compensation Range: 10..50 pF

Max. Input Voltage: 2500Vp CAT I, DC incl. Peak AC (derating with frequency)
