Wi-Fi Wireless Network Analyzer Shineway WFT-20

• Multi-wavelength selectable: 650/850/1300/1310/1490/1550/1625 nm
• 650 nm visible laser source for break and macrobend detection
• Modulation in CW and modulated frequencies
• Modulation frequencies in 270,1K, 2KHz (1Hz@650nm)
• 1625nm laser source with optical power meter to measure upper limit loss in DWDM



• Auto and manual splicing
• Splicing=9s, heating=25s(time and power adjustable)
• Arc counter prompts electrode change upon usage
• Auto arc optimization



• 5.7" Turn-over LCD screen for clear display Both X and Y axis display
• Fiber core can be display clearly
• Inner light to set fiber in dark environment Auto check fiber end-face
• Auto calculate splicing loss
• 9 seconds splice time and selectable heating mode
• 3 hours fast recharge
• 60 preset/user-definable splicing programs



• Analysis and evaluation of SDH and PDH networks andequipment up to 155Mbps.
• According to ITU.T G.821, G.826, G.828,G.829, M.2100, M.2101.
• Tandem Connection Monitoring (TCM) and APid tests.
• Support pointer adjustment test.
• Automatic Protection Switching (APS).
• Round trip delay measurement (STM-1 and E1).



• Result display in histogram and list
• Applicable to normal optical power measurement
• Internal clock & fiber S/N editable
• User definable threshold setting



• ITU-T G.650 recommended method for PMD characterization:
• Accurate total PMD, PMD coefficient
• Fully support 10G/40G/100G DWDM optical network upgrade test
• Compliant with G.650.2, EIA/TIA FOTP-124 & IEC-61941
• High dynamic range for long span measurement 40dB or 200Km
• Easy to use touch screen
• External ports: RG45x1, RS232x1, USBx2, VGAx1



• Pocket-size/pen-size, easy to use
• Fast response, no warm up
• CW/1 Hz mod
• 10Km for Max.measurement Range
• CE, FCC, FDA certificates
• One meter drop test



• Easy to use, reliable
• Fast identification of deep buried, overhead and pipe fiber cable
• Built-in intelligent mode, knock in the measured cable screen showed positive and negative Pyramid strength; output the notification sound



• Peak power and Peak/Average Ratio measurement
• Burst power measurement
• CW power measurement
• Monitor function & test data saving



• OPM-15 Optical Power Meter
• SLS-21 Stabilized Laser Sources
• Applicable on singlemode/multimode fibers
• Quick response, no warm-up
• Interchangeable connectors: FC/SC/ST
