Water Leak detectors | SEBAKMT

Seba KMT Hydrolux HL 5 Water Leak Detector
OBSOLET PRODUCT ( * OUT OF USE )

Code: Seba-KMT Hydrolux HL5 HL-5

Datasheet

PDF, 0.29 Mb

Description

Hydrolux HL 5

The new HL 5 from SebaKMT is a professional and very flexible mini water leak detection unit with both visual and audible indication of the leak and with wireless transmission of the leak noise. It belongs in the jacket pocket of every water specialist and fitter for an instant, on the spot leak monitoring check.

Wireless transmission of the leak noise to the headphones provides maximum freedom of movement. The extremely sensitive piezo-ceramic sensors with automatic level control enable excellent quality analyses even on plastic piping.

Whether used as a sensor rod or as a ground microphone: three filter settings allow the unit to be ideally configured for every leak situation.

The built-in light is great for dark corners and is a very practical companion for night work and for cellars.

Benefits:

Excellent, optimised audio characteristics
3 fixed filter settings
Mute setting (no hissing in the headphones)
Wireless noise transmission
Built-in LED light

All advantages at a glance

»» Pocketsize

»» Mute setting (no static noise in the headphones)

»» 3 optimized fi lter settings

»» Excellent, optimised audio characteristics

»» Optional adapter, for use as ground microphone

»» Easy, one-button operation

»» Immediate detection of leaks

»» Wireless noise transmission

»» Built-in LED light for night work

»» Wireless range 20 m

»» 10 level LED display

Standard accessories

Scope of delivery

»» HL 5 with FM transmitter (863 MHz)

»» Wireless headphone with FM receiver

»» 2 batteries 1.5 V AA for HL 5

»» 2 batteries 1.5 V AAA for headphones

»» 1 extension rod and magnet

»» 1 transport case

»» 1 set of operating instructions

Recommended options

Accessories

»» Tripod (PAM U-D)

»» Valve adapter (S42)

»» Valve adapter (S20)
