Fluke VT04A Infrared Thermometer with Integrated Camera

• Calibrates over 15 different categories of general-purpose test equipment
• Options for power meter, insulation/continuity tester and oscilloscope calibration
• Semi-automated and fully automated procedure modes
• Fully supported by MET/CAL Plus software
• Intuitive front panel operation for ease of use



• True-RMS AC and DC voltage measurements to 1000V
• True-RMS AC and DC current with 0.01 mA resolution
• Temperature measurements from -200 °C to 1372 °C
• True-RMA AC current measurements to 400 A

• Energy loss calculator
• Real-time analysis of trends using the cursors and zoom tools
• Highest safety rating in the industry
• Measure all three phases and neutral
• Automatic Trending
• Ten power quality parameters on one screen according to EN50160 power quality standard
• Logger function



• Backlit display for poorly lit areas
• Last ten temperature readings displayed on bar graph for easy reference
• Enhanced optics (distance to spot ratio up to 60:1) allow measurements of smaller objects from farther away
• Coaxial three-dot laser sighting system highlights the true diameter of measurement spots at all distances (90% energy)
• MIN/MAX measurements calculations instantly computed
• Audible and visible HI temperature alarm for instant recognition



• 70 V to 300 V Operating Voltage
• Fast and easy recording of voltage trends, dropouts, and power quality
• Continuous recording of all values with no gaps
• Flicker recording to EN 61000-4-15, individual harmonic and THD values
• Min, Max, and Average RMS values

• Test voltage: 50V, 250V, 500V, 1000V
• Two measurements at once and a dual display
• PEFC/PSC and loop impedance
• Fast voltage measurement between L-N, L-PE and N-PE
• PASS/FAIL indication for RCD test results
• Earth resistance



• hand operated hydraulic pressure pump
• designed to generate calibration pressures up to 10,000 psi/690 bar
• Variable size stroke adjustment, allows the user to vary the volume and pressure per stroke
• Integral pressure adjustment vernier knob for fine pressure adjustment
• Directly connection to pressure modules consolidates two separate pieces into one when performing pressure calibration and testing
• Two ¼ inch NPT pressure ports, one for reference (pressure module or gauge), one for UUT
• Improved priming
• Improved stroke limiting mechanism



• On-board identification and location of the most common mechanical faults (bearings, misalignment, unbalance, looseness) focus maintenance efforts on root cause, reducing unplanned downtime
• Fault severity scale with four severity levels helps you prioritize maintenance work
• Repair recommendations advise technicians on corrective action
• On-board context sensitive help provides real-time tips and guidance to new users
• 2 GB expandable on-board memory provides enough space for your machinery’s data



• 200 A AC and DC current measurement with detachable jaw
• 600 V AC and DC voltage measurement
• True-rms AC voltage and current
• 6000 O resistance measurement



• Precision pressure measurement from -20 mbar to 690 bar
• Absolute pressure measurement ranges 15, 30, 100, 300 psia
• Accuracy to 0.05 % of full scale
• Reference class gauge accuracies to 0.04 % of reading
• Easy to use, rugged construction for reliable performance
