FLUKE ii905 Acoustic Camera Imager for Inspectina and Detection Compessed Air

Code: ii905 FLK-II905 5594650




Datasheet PDF, 1.99 Mb


Description

Easy, fast, and safe visual detection of compressed gas leaks with LeakQ  mode including estimated leak size and cost.
The 7" LCD touchscreen overlays a SoundMap on visual images, facilitating rapid leak location identification.
The integrated visual- and textual tagging and annotation functionalities offer important details to optimize reporting and follow-up actions.
On-the-go wireless upload to Fluke Connect

Fluke ii905 Acoustic Imager with LeakQ™: Detect, Locate, and Assess Gas Leaks

The Fluke ii905 Acoustic Imager equipped with LeakQ™ acoustic leak detection technology empowers maintenance teams to efficiently detect, locate, and assess gas and vacuum leaks. Whether you're dealing with compressed air systems, pipelines, or industrial equipment, the Fluke ii905 provides valuable insights to optimize your operations.

Key Features:

Ready-to-Use: The Fluke ii905 comes ready out of the box. Its rugged, ergonomic design ensures easy handling, while the large 7" LCD display provides clear leak visualization.
Quick Detection: Even users with minimal experience can start detecting leaks within minutes. The tool estimates leak size and cost, incorporating a new distance-estimation feature and the 1-10 LeakQ™ severity index.
SoundMap™ Overlay: The 7" LCD touchscreen overlays a SoundMap™ on visual images, facilitating rapid leak location identification.
Intuitive Interface: Easily isolate leak sound frequencies and filter out background noise.
Tagging and Organization: Use image and video tagging, annotation, and folders for efficient organization.
Leak Sizing: Prioritize repairs based on leak size.
Collaboration: The reporting tool allows seamless sharing of visuals, tagging, and notes with team members and repair personnel.
Money-Saving Insights:

Did you know that a 100 hp air compressor can consume around $50,000 in electricity annually? Shockingly, up to 30% of that electricity is wasted due to pressurizing airlines that leak. Many facilities overlook assessing the efficiency of their compressed air systems, leading to unnecessary capacity additions. The Fluke ii905 helps you identify leaks, optimize energy usage, and reduce costs.

LeakQ™ Mode:

Automatic Distance Estimation: When a leak is detected, the imager determines the distance to the target (indicated inside the circle on the display). The LeakQ value on the screen reflects the leak's size, based on measured dB SPL value and distance.

Comprehensive Reporting:

The LeakQ reporting tool combines data from your Fluke ii905 Acoustic Imager with direct inputs to create organized and detailed reports. These reports guide repairs, confirm fixes post-repair, and document the inspection process and results.

LeakQ online reporting tool

Local PC installed application
No Leak Type selection (should be included at the time of capturing the measurement)
Offers customization of reporting template



Standard accessories

FLK-II905
Fluke ii905 Acoustic Imager

Part#: 5594650


Includes:

Fluke ii905 Acoustic Imager
USB-C Charger with country-specific connectors
Rugged lithium-ion smart battery pack
USB-C cable
Rugged, hard carrying case
Adjustable hand strap and neck strap
Sensor array protector
