Extech SD750 3-Channel Pressure Datalogger

Code: Extech SD750




Datasheet PDF, 0.36 Mb

Description

Records data to SD card in Excel® format

Extech's 3-Channel Pressure Data logger allows technicians to easily monitor and record pressure levels from three sources using one meter instead of three. Applications include pressure measurements from hydraulic, pneumatic, air compressor and process gas systems, as well as other industrial applications. Complete with six AAA batteries, 2G SD card, universal AC adaptor, 3 connectors, and mounting bracket.



Features:

  • Triple LCD simultaneously displays 3 pressure channels
  • Up to 5000psi with 4-20mA output
  • 4-20mA input with readout in 9 units of measure
  • Datalogger date/time stamps and stores readings on an SD card in Excel® format
  • User-selectable data sampling rate: 5, 10, 30, 60, 120, 300, 600 seconds or auto
  • Complete with six AAA batteries, SD memory card, universal AC adaptor, three connectors, and mounting bracket
