Mini MPS (Modular Production System) ED-9160

• High-performance digital synthesizer method
• Wide Frequency Coverage : 9 kHz ~ 3.0 GHz
• Superior Resolution : Minimum 1 Hz
• Compact & Portable size
• Pre Amp as standard
• Wide Input Dynamic Range : -130 ~ 20 dBm
• Various and Convenient Interfaces : USB, LAN



• OP-Amp. characteristics and various appplication circuits
• Main Frame contains DC Power Supply, AF Signal and Frequency Counter



• Mountable 5pieces MCU(8051,PIC, ATmega128, ATmega8535, upd78F0547)
• Practice of various communications such as RS-232 USB and Ethernet
• SoC experiments using the default FPGA (EP1C4F324)
• Storage of sensor data display and excel data using UI(LabVIEW)



• PC-based multi-function instrument for electricity/electronics and other experiments
• Digital Storage Oscilloscope with the 2-channel simultaneous 50MS/s sampling rate
• Spectrum Analyzer functions using Digital Storage Oscilloscope(DSO)
• Variable Power Supply(VPS), Function Generator(FG), Analog Output and Digital Output
• Analysis of collected data on PC through the modules of DSO, DMM, FC and Analog/Digital Input
• Numerical and graphical indication of the data measured and analyzed in real time



• Gunn Oscillator base system
• Directional Coupler & Horn Antenna
• Frequency : 9GHz~11GHz (X-Band)
• Microwave output : 15mV



• Hexadecimal number indicators
• Selectable pulse outputs
• Built-in DC power supp



• Remote mode by PC and Local mode by manual operation on the panel
• Graphical display of diagrams on panel for AD/DA conversion procedures
• DSO embodiment by A/D Converter for collection and analysis of analog data on PC
• Storage of measured data and generation of 5 wave forms required for experiments through D/A Converter



• Panel type structure for good grasp of entire network configuration
• Learning about the functions and characteristics of basic network equipments such as NIC, HUB, Router and DSU, plus installation and maintenance
• Interlocking experiments with Internet for clear understanding a real network
• Capable of conneting to the open network on campus



• Aluminum Profile-based work table structure for mounting the components
• Manufacturing electrical composition elements in modular type using actual components
• Wiring practices and circuit composition to configure sequence composition elements on the working board
• Various contents linked with e-learning such as wiring, operation and etc.



• Monitoring of internal data through the 4-digit LED
• LD (Ladder Diagram), IL (Instruction List), SFC (Sequential Function)
• Stepping motor and DC motor installed as standard for rotational / linear movement
• Basic 3 Modules : Input Controller, Output Simulator, Count & Position Simulator
