Motor Input Voltage
- AC Motor
- 110V, 60Hz(2-Phase)
- 220V, 60Hz(3-Phase)
- DC Motor : 110V DC
Generator Output Voltage
- AC Generation : 110V/220V, 60Hz
- DC Generation : 110V
Dimension
- Motor/Generator : 240(W) x 276(H) x 345(D)mm
- Panel Equipment : 480(W) x 180(H) x 210(D)mm
- M/G Mounting Base : 810(W) x 70(H) x 395(D)mm
- Bench-Top Console(BTC-180-6)
- 1500(W) x 790(H) x 380(D)mm (with ED-5100-2 or ED-5100-3)

ACCESSORIES

Patch Cord(�4 Plug) : 1set
Experimental Manual(DC, AC) : 2ea

More products ED

STEPPING MOTOR TRAINER ED-4301

• Graphical display of functonal block diagram on the system suface
• Real-time monitoring and control by PC Control Program
• LM Guide and Rotary Encoder for position control
• Displays moving distance and angle data using LCD

ALLEN-BRADLEY SLC-500 MODULAR PLC TRAINER ED-4260AB

• ALLEN-BRADLEY SLC-500 PLC programming and execution
• Modularization of the devices essential for PLC I/O commands
• Experiments for basic command and various application program
• Binary data experiments with 4digits digital switch and display unit
• Customizable for various types of SLC-500 Series CPU upon request

HYDRAULICS TRAINER ED-7960

• Convenient parts fixation by �one-touch lever’ bases and aluminum profile structure
• Efficient space utilization by mounting parts horizontally/vertically
• 64 hydraulic and electrical/electronic parts plus 20 types of optional components.
• Various hydraulic devices and components for Flexible Manufacturing System

PULSE/DIGITAL COMMUNICATION TRAINER ED-2920

• Modularized by each communicarion type
• PAM, PTM, PCM, DPCM, ADPCM, LDM, ADM, Delta-sigma
• No need to have additional generators (built-in power supply and signal source)
• Can display the test point and measure signals using an oscilloscope

EMBEDDED SOFTWARE DESIGN PLATFORM ED-255EK

• Basic to advanced learning courses for Embedded Linux
• Intel PXA255(400MHz) high-performance microprocessor
• 6.4TFT LCD, Ethernet 2port, Serial 3port, PCMCIA/CF/MMC interfaces
• FPGA Chip(Altera Cyclone 120,000Gate) mounted for SoC experiments
• Reliable hardware and abundant experiment contents for programming

BLOCK MODULAR PRODUCTION SYSTEM ED-9150

• Small size type suitable for traning on automation system’s installation and operation
• Mechanism and installation methods through assembly and disassembly per process
• Enhancement of application programming techniques through PLC control

PC BASED RFID TRAINER ED-1450

• The electronic manual operable on PC comes with ED-1450 and e-learning is optimized by remote control of student’s operating program and evaluation of student’s online report in real time.
• Through DS-1410, it provides Variable Power Supply(VPS), Function Generator(FG), Analog Output, Digital Output needed for experiments.

COMPUTER BASED INSTRUMENT SYSTEM CBIS-1400

• PC-based multi-function instrument for electricity/electronics and other experiments
• Digital Storage Oscilloscope with the 2-channel simultaneous 50MS/s sampling rate
• Spectrum Analyzer functions using Digital Storage Oscilloscope(DSO)
• Variable Power Supply(VPS), Function Generator(FG), Analog Output and Digital Output
• Analysis of collected data on PC through the modules of DSO, DMM, FC and Analog/Digital Input
• Numerical and graphical indication of the data measured and analyzed in real time

POWER ELECTRONICS TRAINER ED-2040

• Covers essential circuits needed to practice power electronics circuits
• Modular type with aluminum carrying case
• Optional rack to be customized upon requst

SQUIRREL CAGE INDUCTION MOTOR/ DC GENERATOR MG-5212

• Start and load characteristics of squirrel cage induction motor
• Alteration of the rotative directions of squirrel cage Induction Motor
• Slip speed and torque of induction motor
• Induction motor’s no-load power factor and load power facto
