BAUR CL 20 Cable Locator

Code: BAUR CL 20




Datasheet PDF, 0.28 Mb


Description

The CL 20 cable locator comprising a transmitter and a receiver is used to determine the exact location of cables and metal pipes. The ability to determine laying depths of up to 4.5 m and to measure signal currents at the touch of a button allows you to obtain reliable information on the position of the cable within the shortest time.



Features:

  • Fast and exact location of position and laying depth of cables
  • Intuitive operation ½ no special measurement knowledge required
  • Lightweight and manageable
