Options
Insulation test (500V)	add /N to part number
Analysis function (graphs)	add /G to part number
LF Telecom function	add /T to part number
Bin Handler	add /D to part number

Auxiliary unit
25A DC bias unit 3265B (1 MHz) Supplied with user manual, power cable, spare fuses, 4 x BNC to BNC links, daisy chain link, rack mounting ears (unit needs rear support) and bus bars.		1J3265B

25A DC bias unit 3265BQ (3 MHz) Supplied with user manual, power cable, spare fuses, 4 x BNC to BNC links, daisy chain link, rack mounting ears (unit needs rear support) and bus bars.		1J3265BQ

Accessories
1009 DC Bias Fixture		1J1009
Rack mounting kit, 3U x full width		1EXA20230
Kelvin clips (fine jaws). (2 sets recommended for transformer tests)		1EVA40100
Kelvin clips (large jaws)		1EVA40180
BNC to 4-terminal component fixture (Recommended above 500 kHz)		1EV1006
4-terminal lead set		1EV1505
SMD Tweezers		1EVA40120
