Radio Wave Absorber Materials for Wideband Emissions TDK

• Frequency Range: 20 MHz to 6 GHz
• Gain: 6 dBi typical
• VSWR: 2:1 average
• Polarization: Linear
• Power Handling: 100 W
• Input Impedance: 50 ohms nominal
• Excellent low frequency response
• Unique internal balun provides balance even under adverse conditions



• Best-in-Class Test Instruments
• Fully Integrated Hardware and Software
• Remote Control of Switches, Positioning Devices, and LISNs
• Automated, Semi-automated, and Manual Testing
• Ergonomically Designed Test Consoles and Racks
• High Quality System Cabling and Connectors
• Quality Workmanship
• On-Site Training
• Comprehensive Warranty



• The measurement system is an easy to use, flexible package optimized for dosimetric evaluation of radio products
• The package includes Data Acquisition Electronics and system control computer.
• Probes and Measurement Accessories
• Position Controller and Positioning Robot
• System Verification and Support
• System Controller with Application Software



• Frequency Range: 26 MHz to 3 GHz
• Gain: 6 to 8 dBi typical
• VSWR: <2:1 average
• Polarization: Linear
• Power Handling: 1.0 kW maximum



• Frequency Range: 20 MHz to 600 MHz
• VSWR: 2.5:1 average
• Polarization: Linear
• Feedpoint Impedance: 50 ohms nominal
• Improved balun provides superior patterns and balance
• Improved biconical element design



• 10kHz - 100 MHz operating range
• High power field generator
• Up to 500 V/m RSM
• Low VSWR
• Adjustable height for optimizing performance



• Dimensions: 7.0 m long x 3.0 m wide x 3.0 m high
• Absorbers: X-131 Fully lined double layer ferrite
• Radiated emissions: Compliance with EN 50147-2
• Radiated immunity: Compliance with IEC 1000-4-3
• EMI frequency range: 30 MHz - 1 GHz
• EMS frequency range: 26 MHz - 1 GHz
• Radiated emissions: Pre-compliance with EN 50147-2, ANSI C63.4, CISPR 22
• Radiated immunity: Full compliance with IEC 1000-4-3



• Immunity measurements to automotive test regulations
• Excellent linear response
• Designed to SAE specifications
• Capable of handling high power
• Integrated test table



• Frequency Range: 20 MHz to 300 MHz
• VSWR: 2.5:1 average
• Polarization: Linear
• Power Handling: 3500 W continuous
• Feedpoint Impedance: 50 ohms nominal
• Improved balun provides superior patterns and balance



• Best-in-Class Test Instruments
• Fully Integrated Hardware and Software
• Remote Control of Switches and Positioning Devices
• Automated, Semi-automated, and Manual Testing
• Built-in System and Operator Safety
• Ergonomically Designed Test Consoles and Racks
• High Quality System Cabling and Connectors
• Quality Workmanship
• On-Site Training
• Comprehensive Warranty
