Washdown Compact Bench Scale Ohaus BW

Code: Ohaus BW




Datasheet PDF, 0.27 Mb

Description

• Four popular capacity models: 1.5 kg x 0.2 g, 3 kg x 0.5 g, 6 kg x 1 g, 15 kg x 2 g

• Maximum displayed resolutions from 1:6000 - 7500

• Type approved resolution 1:3000

• Durable high-profile ABS housing with stainless steel pan (pan is dishwasher-safe)

• IP65 dust and water jet protection

• Four adjustable rubber leveling feet with integral front-panel leveling indicator

• One red LED weight display: 6-digit, 7-segment, 14 mm high characters, adjustable brightness level

• Fast display = 2 seconds

• Four raised tactile mechanical buttons: On/Off, Check, Tare, Zero

• Two weighing units: kg or g

• AC or Internal Rechargeable lead-acid battery

• 50-hour internal rechargeable battery with power-saving Auto-shut off feature

• Voltage level indication

• Over-Under checkweighing function



Recommended options

MODEL CODE

ITEM NR.

CAPACITY

READABILITY

PLATFORM

BW1.5

80250430

1.5kg

0.2g

230x180mm

BW3

80250431

3kg

0.5g

230x180mm

BW6

80250432

6kg

1g

230x180mm

BW15

80250433

15kg

2g

230x180mm

BW1.5-M

80250434

1.5kg

0.5g

230x180mm

BW3-M

80250435

3kg

1g

230x180mm

BW6-M

80250436

6kg

2g

230x180mm

BW15-M

80250437

15kg

5g

230x180mm
