Agilent U2741A Modular USB Digital Multimeter 5.5 digit

Code: Agilent U2741A




Datasheet PDF, 1.25 Mb

Description

  • 5.5 digit
  • 0.02% accuracy
  • USB PC based Multimeter
  • Make fast measurements with up to 100 readings/s
  • Measures up to 300Vdc with 5.5 digits resolution
  • Frequency and temperature measurement capability
  • Utilize wide measurement ranges: 100 mVdc to 300 Vdc and 10 mA to 2 A
  • High-speed USB 2.0, USBTMC-USB488 standard (compatible with Microsoft® Windows® operating systems)
  • Standalone and modular capabilities
