Agilent 6611C 6612C 6613C 6614C Programmable Multiple Power Supply 25-160W

Code: Agilent 6621A 6622A 6623A 6624A 6625A 6626A 6627A 6628A 6629A




Datasheet PDF, 0.29 Mb

Description

  • Multiple sources in an integrated one-box solution
  • Dual-range linear outputs
  • 2, 3 or 4 independent isolated outputs
  • Stable, low ripple and noise power source
  • Overvoltage & overcurrent Protection features to ensure DUT safety
  • low-noise outputs
  • Built-in measurements and advanced programmable features
  • Fast up & down programming
  • Measured V & I readback over GPIB
  • UL/CSA


Recommended options

  • 6621A Dual Output 2x(80W, 1x7V/10A or 1x20V/4A)
  • 6622A Dual Output 2x(80W, 1x20V/4A or 1x50V/2A)
  • 6623A Triple Output 1x(40W, 1x7V/5A or 1x20V/2A), 1x(40W, 1x20V/2A or 50V/0.8A), 1x(80W, 1x7V/10A or 1x20V/4A)
  • 6623A-J03 Triple Output 2x(40W, 1x20V/2A or 50V/0.8A), 1x(105W, 1x35V/3A)
  • 6624A Quad Output 2x(40W, 1x7V/5A or 1x20V/2A), 2x(40W, 1x20V/2A or 50V/0.8A)
  • 6625A Dual Output 1x(25W, 1x7V/0.015A or 1x50V/0.5A), 1x(50W, 1x16V/0.2A or 1x50V/1A or 1x16V/2A)
  • 6626A Quad Output 2x(25W, 1x7V/0.015A or 1x50V/0.5A), 2x(50W, 1x16V/0.2A or 1x50V/1A or 1x16V/2A)
  • 6627A Quad Output 4x(40W, 1x20V/2A or 50V/0.8A)
  • 6628A Dual Output 2x(50W, 1x16V/0.2A or 1x50V/1A or 1x16V/2A)
  • 6629A Quad Output 4x(50W, 1x16V/0.2A or 1x50V/1A or 1x16V/2A)
