Handheld Digital Multimeter ATEX Safe 4.5 digit Fluke 87V Ex

Code: Fluke 87V-Ex




Datasheet PDF, 0.14 Mb

Description

  • 4.5 digit
  • 6000 count resolution for precise measurements
  • 0.05% basic accuracy
  • True-rms ac voltage and current for accurate measurements on non linear signals
  • Selectable filter for accurate voltage and frequency measurements on motor drives
  • Built in thermometer lets you carry one less tool (TC probe included)
  • ATEX safety rating Ex II 2 G Eex ia IIC T4
  • Measure up to 1000 V ac and dc
  • Measure up to 10 A, 20 A for up to 30 seconds
  • Frequency to 200 kHz and % duty cycle
  • Resistance, continuity and diode test
  • 10,000 µF capacitance range for components and motor caps
  • Min/Max-Average recording with Min/Max Alert to capture variations automatically
  • Peak capture to record transients as fast as 250 µs
  • Relative mode to remove test lead interference from low ohms measurements
  • Auto and manual ranging for maximum flexibility
  • Touch Hold to capture stable readings avoiding noisy signals
  • Large display digits and two-level bright white backlight for increased visibility
  • Analog bargraph for fast changing or unstable signals
  • Input Alert provides audible warning against wrong use of input jacks
  • Improved selectable sleep mode for long battery life
  • Access door for fast battery changes without breaking the calibration seal
  • "Classic" design with new removable holster with built in test lead and probe storage
  • Lifetime warranty


Standard accessories

  • TL75 test leads
  • AC72 alligator clips
  • yellow holster (H80M excl. TPAK)
  • 80BK temperature probe
  • 9 V battery (installed)
  • CD-ROM user’s manual and technical notes
  • operator’s guide


More products FLUKE

FLUKE 190-204 190-204/S HANDHELD SCOPEMETER OSCILLOSCOPE 4X200 MHZ

• 4-channels isolated 200MHz
• CAT III 1000V / CAT IV 600V safety rated
• Dedicated 5000 Count digital multimeter in two-channel models
• Advanced automatic measurements, power (Vpwm, VA, W, PF) and time (mAs, V/s, w/s)
• IP-51 rated for dust and drip proof to withstand harsh environments
• Isolated USB ports for memory devices and PC connectivity



VOLTAGE CONTINUITY TESTER FLUKE T120

• LED Bargraph
• Display: Fluke T120: 3½ digit LCD
• Voltage test
• Optical and acoustical continuity test



FLUKE 1654B MULTIFUNCTION INSTALLATION TESTER 50V-1000V

• Test voltage: 50V, 100V, 250V, 500V, 1000V
• Two measurements at once and a dual display
• PEFC/PSC and loop impedance
• Fast voltage measurement between L-N, L-PE and N-PE
• PASS/FAIL indication for RCD test results
• Earth resistance



INFRARED NON-CONTACT THERMOMETER FLUKE 572

• Backlit display for poorly lit areas
• Last ten temperature readings displayed on bar graph for easy reference
• Enhanced optics (distance to spot ratio up to 60:1) allow measurements of smaller objects from farther away
• Coaxial three-dot laser sighting system highlights the true diameter of measurement spots at all distances (90% energy)
• MIN/MAX measurements calculations instantly computed
• Audible and visible HI temperature alarm for instant recognition



FLUKE 700G PRECISION PRESSURE TEST GAUGE

• Precision pressure measurement from -20 mbar to 690 bar
• Absolute pressure measurement ranges 15, 30, 100, 300 psia
• Accuracy to 0.05 % of full scale
• Reference class gauge accuracies to 0.04 % of reading
• Easy to use, rugged construction for reliable performance



FLUKE 2042 CABLE TRACE LOCATOR FOR

• for tracing cables in walls and underground
• locating fuses/breakers on final circuits
• locating interruptions and short-circuits in cables and electrical floor heating systems
• for tracing metallic water and heating pipes



CURRENT CLAMP METER TRUE-RMS AC/DC FLUKE 381

• Detachable digital display, read measurements up to 30 feet away
• iFlex fexible current probe included, 18-inch circumference
• 2500 A AC current measurement with iFlex
• 1000 A AC current measurement with fxed jaw
• 1000 V AC and DC voltage measurement
• True-rms AC voltage and current
• Frequency measurement to 500 Hz
• 60-k O resistance measurement
• 500 mV DC measurement range
• 1000 µF capacitance measurement



LASER DISTANCE METER 100M FLUKE 424D

• The ultimate Fluke laser distance meter
• Measures up to 100 m (330 feet)
• Feature-rich meter includes tilt sensor for hard-to-reach measurements, corner angle feature and compass



BATTERY RESISTANCE ANALYZER FLUKE BT521

• Key measurements: Battery resistance, dc and ac voltage, dc and ac current, ripple voltage, frequency and battery temperature.
• Enhanced data analysis: Quickly compare trends, analyze results and create reports with included battery management software.
• Easy reporting: Generate PDF report on the PC software with analysis graphics and data table or quick email format report with csv file on the mobile app.
• Wireless communication
• USB Port



CURRENT CLAMP METER TRUE-RMS AC/DC FLUKE 375

• iFlex fexible current probe compatible
• 600 A AC and DC current measurement with fxed jaw
• 2500 A AC current measurement with iFlex (sold separately)
• 600 V AC and DC voltage measurement
• True-rms AC voltage and current
• Frequency measurement to 500 Hz
• 60 k O resistance measurement
• 500 mV dc measurement range
• 1000 µF capacitance measurement
