Fluke 1630 Earth Ground Clamp Meter

Code: Fluke 1630




Datasheet PDF, 0.87 Mb

Description

  • A wide ground loop resistance range, from 0.025 O to 1500 O, to satisfy all requirements
  • Large jaw opening of 35 mm (1.38 in) for tests on ground conductors and/or equipotential bus bars
  • Measurement of ground leakage current, from 0.2 mA to 1000 mA, without needing to disconnect - ideal for system troubleshooting
  • Wide ac current measurement range from 0.2 A to 30 A allows one instrument for multiple applications
  • User-defined HI / LO Alarm limits, for rapid measurement evaluation
  • Handy 'display hold' button for capturing readings in hard-to-reach places
  • Time saving memory function automatically records and stores measured values
  • Automatic self calibration ensures correct measurement every time
  • Overload protection: 200 A
  • Carrying case and resistance test loop included
  • = 8 hours battery life (continuous operation)


Standard accessories

  • Rugged carrying case with shoulder strap
  • Resistance test loop
  • 9 V battery
  • User's manual
