FLUKE Ti200 Infrared Camera 200x150 Resolution

Code: Fluke Ti200 FLK-Ti200




Datasheet PDF, 1.44 Mb

Description

  • Detect and communicate issues faster with patented Fluke IR-Fusion® technology with AutoBlend™ mode
  • Faster communication with wireless image transfer directly to your PC, Apple® iPhone® or iPad®
  • Fluke Connect™ App - See It. Save It. Share It. All the facts, right in the field
  • One-handed, easy-to-use user interface
  • Ruggedized high resolution 640x480 capacitive touch screen for quick menu navigation
  • Capture additional digital images to show location or additional site details with IR-PhotoNotes™ Annotation System
  • More advanced display output options to get the details via streaming video to PC or high definition monitor (USB and HDMI)
  • Voice recording and annotation gets additional details saved with the image file
  • Optional interchangeable lenses for greater flexibility in additional applications
  • Rechargeable, field replaceable smart batteries with LED display to show charge levels for excellent field flexibility
  • 5 MP industrial-performance digital camera for high definition image quality
  • Included SmartView® and SmartView Mobile App Analysis and Reporting Software


Standard accessories

Model Name

Description

FLK-Ti200 9 Hz

Fluke Ti200 Thermal Camera (9 Hz)
Includes:

  • Thermal camera with standard infrared lens
  • AC power supply and battery pack charger (including mains adapters)
  • Two, rugged lithium ion smart battery packs
  • USB cable
  • HDMI video cable
  • SmartView® software available via free download
  • Rugged, hard carrying case
  • Soft transport bag
  • Adjustable hand strap
  • Warranty registration card
  • International adapter set (9 Hz only)

FLK-Ti200 60 Hz

Fluke Ti200 Thermal Camera (60 Hz)
Includes:

  • Thermal camera with standard infrared lens
  • AC power supply and battery pack charger (including mains adapters)
  • Two, rugged lithium ion smart battery packs
  • USB cable
  • HDMI video cable
  • SmartView® software available via free download
  • Rugged, hard carrying case
  • Soft transport bag
  • Adjustable hand strap
  • Warranty registration card

FLK-Ti300 9 Hz

Fluke Ti300 Thermal Camera (9 Hz)
Includes:

  • Thermal camera with standard infrared lens
  • AC power supply and battery pack charger (including mains adapters)
  • Two, rugged lithium ion smart battery packs
  • USB cable
  • HDMI video cable
  • SmartView® software available via free download
  • Rugged, hard carrying case
  • Soft transport bag
  • Adjustable hand strap
  • Warranty registration card
  • International adapter set (9 Hz only)

FLK-Ti300 60 Hz

Fluke Ti300 Thermal Camera (60 Hz)
Includes:

  • Thermal camera with standard infrared lens
  • AC power supply and battery pack charger (including mains adapters)
  • Two, rugged lithium ion smart battery packs
  • USB cable
  • HDMI video cable
  • SmartView® software available via free download
  • Rugged, hard carrying case
  • Soft transport bag
  • Adjustable hand strap
  • Warranty registration card

FLK-Ti400 9 Hz

Fluke Ti400 Thermal Camera (9 Hz)
Includes:

  • Thermal camera with standard infrared lens
  • AC power supply and battery pack charger (including mains adapters)
  • Two, rugged lithium ion smart battery packs
  • USB cable
  • HDMI video cable
  • SmartView® software available via free download
  • Rugged, hard carrying case
  • Soft transport bag
  • Adjustable hand strap
  • Warranty registration card
  • International adapter set (9 Hz only)

FLK-Ti400 60 Hz

Fluke Ti400 Thermal Camera (60 Hz)
Includes:

  • Thermal camera with standard infrared lens
  • AC power supply and battery pack charger (including mains adapters)
  • Two, rugged lithium ion smart battery packs
  • USB cable
  • HDMI video cable
  • SmartView® software available via free download
  • Rugged, hard carrying case
  • Soft transport bag
  • Adjustable hand strap
  • Warranty registration card


Recommended options



Thermal Imaging Accessories

FLK-TI-VISOR3

Infrared Camera Visor
Sun Visor for Ti400, Ti300 and Ti200 Infrared Cameras.

FLK-TRIPOD3

Tripod Mounting Base
Use with Ti400, Ti300 and Ti200 Infrared Cameras.

BOOK-ITP

Introduction to Thermography Principles Book

FLK-LENS/TELE2

Telephoto Infrared Lens (2X magnification)
For use with Ti400, Ti300 and Ti200 Infrared Cameras.

FLK-LENS/WIDE2

Wide-angle Infrared Lens
For added versatility and special applications use with Ti400, Ti300 and Ti200 models.



Batteries, Chargers & Adapters

FLK-TI-SBC3B

Charging base for Ti-SBP3 Rechargeable Lithium-Ion Battery Packs. Use with models Ti400, Ti300, Ti200, Ti125, Ti110, Ti105, Ti100, TiR125, TiR110, TiR105, Ti32, TIR32, Ti29, TiR29, Ti27 and TiR27.

FLK-TI-SBP3

Extra battery pack for Ti400, Ti300, Ti200, Ti125, Ti110, Ti105, Ti100, TiR125, TiR110, TiR105, Ti32, Ti29 and Ti27 Infrared Cameras.

TI-CAR CHARGER

Infrared Camera Vehicle Charger
For the ultimate flexibility in the field - recharge your infrared camera wherever and whenever you need to.
For use with all models except FlexCam.



PC Adapter and Software

FLK-FC-SD CARD

Fluke Connect Wireless SD Card







More products FLUKE

FLUKE 700G PRECISION PRESSURE TEST GAUGE

• Precision pressure measurement from -20 mbar to 690 bar
• Absolute pressure measurement ranges 15, 30, 100, 300 psia
• Accuracy to 0.05 % of full scale
• Reference class gauge accuracies to 0.04 % of reading
• Easy to use, rugged construction for reliable performance



INFRARED THERMOMETER WITH CONTACT THERMOCOUPLE FLUKE 566/ FLUKE 568

• Measure -40 °C to 800 °C /-40 °F to 1472 °F (568) or -40 °C to 650 °C/-40 °F to 1202 °F (566)
• Easily access advanced features with the soft-key buttons and dot-matrix display
• Measure smaller objects from further away, with a distance-to-spot ratio of 50:1 (568) or 30:1 (566)
• Compatibility with all standard miniconnector Type-K thermocouples allow you to preserve your thermocouple investments



LASER DISTANCE METER 60M FLUKE 416D
