Current Clamp Meter True-rms 1000A Agilent U1213A

Code: Agilent U1213A




Datasheet PDF, 0.26 Mb

Description

  • 1000 A DC and True-RMS AC, AC+DC current measurement
  • CAT III 1000V and CAT IV 600V safety protection
  • Small body and large jaw size up to 52mm
  • Includes full-featured DMM with resistance, capacitance, frequency, diode check, continuity
  • K-Type temperature measurements
  • Peak-hold with in-rush current measurement
  • Dual ranging mode, manual and auto
  • Large dual display
  • Manual and auto-ranging for all measurements
  • Min/max recording capability
  • One-hand operation


Standard accessories

  • Test leads
  • 19-mm probes
  • 4-mm probes
  • Soft carrying case
  • Quick Start Guide
  • Certi?cate of Calibration (CoC)


Recommended options

  • U1168A Standard Test Lead Kit
  • U1162A Alligator clips
  • U1175A Soft carrying case
  • U1186A K-type thermocouple and adapter
