DVD & CD Training System Promax ED-845

Code: Promax ED-845




Datasheet PDF, 0.05 Mb

Description

Destinated to the theoretical-practical study of a DVD & CD player, the ED-845 allows to observe the internal composition of the mechanics, analyze the signals that take part of the operation, and to simulate several faults for the study of troubleshooting and diagnostic methods. Includes documentation (theory, practical and professor manuals), a DVD and a CD disc, remote control and a block diagram that shows the generic structure of a player.



SIGNAL FORMAT

PAL/NTSC (without transcoding)

AUDIO RANGE

DDVD (PCM 96 kHz) 0,2 up to 44 kHz, ± 1 dB
DVD (PCM 48 kHz) 0,2 up to 22 kHz, ± 0,5 dB
CD 0,2 up to 20 kHz

DYNAMIC RANGE

103 dB (DVD), 99 dB (CD)

AUDIO SYSTEMS

MPEG-2, AC-3 5.1 canales, Dolby surround

Pro-Logic, PCM 1 up to 8 channels, DTS 6

channels
