PXI Multiplexer Module 64-channels 100V/1A Agilent M9101A

Code: Agilent M9101A

Datasheet

PDF, 0.97 Mb

Description

Switch many different points to a single instrument for data acquisition and automated test applications
64-channel, high-density 2-wire switch multiplexer
100Vrms
0.5A/1.0A switch/carry current
10W max power
High-speed 500 usec reed relays
Break-before-make or simultaneous switch closures
