Agilent 34411A Digital Precision Multimeter 6.5 digit

• 0.1% basic accuracy
• 100 Hz, 120 Hz, 1 kHz, 10 kHz, 20 kHz, 100 kHz test frequencies
• Measurement parameters: Z, Y, Theta, R, X, G, B, C, L, D, Q, Rdc, N, M



• 100 kHz to 7 GHz Frequency range(tunable to 9 kHz)
• 10 Hz to 3 MHz RBW
• 1 Hz to 3 MHz VBW



• 34-channel portable logic analyzer
• 48-channel pattern generator
• 4 GHz (250 ps) timing zoom with 64 K memory
• 1.0 GHz / 500 MHz (half / full-channel) conventional timing with deep memory
• up to 250 MHz State clock rates
• up to 250 Mb/s Data rates
• up to 32 M acquisition memory depth



• Hybrid Dual Transfer Switch
• Broadband from DC to 26.5 GHz
• Unmatched isolation 92 dB at 8 GHz
• Long life cycles - 5 million cycles guaranteed, 10 million cycles typical



• 70 2-wire channels
• Mixed 2- or 4-wire configurations
• High-speed reed relays, with relay counter



• 70 MHz bandwidth
• 2 analog channels
• 1GSa/s per channel sample rate



• High speed USB 2.0 (480MBit/s)
• 16-bit resolution
• simultaneous analog input channels
• up to 500 kSa/s/ch
• 2 12-bit analog output channels
• 1 MSa/s analog output update rate
• 24-bit programmable TTL input/output channels



• 1 mHz to 165 MHz
• 1 or 2 Channels(order 2 x 81111A modules)
• 2 ns to 200 ms variable transition time
• Up to 10 Vpp into 50 O (20 Vpp into open circuit)



• Quad 4-channel multiplexers
• DC to 1.5 GHz, 75 Ohm
• High isolation, low VSWR
• 30V, 0.5A, 10W switching
• 75 Ohm mini SMB connectors



• 6 ½ digit resolution
• Basic accuracy: .0030 % DC,0.06% AC
• 14 measurement functions including capacitance & temperature
• 50,000 readings/sec. @ 4 1/2 digits to the PC
• 1M reading memory
